No. Back-stab or push-in termination relies upon a feature formed by the brass contact (see image) and is limited to 15A and 14AWG solid wire. EdgeConnect termination uses a patented spring clamp to apply continuous pressure and accepts 14-10AWG solid or stranded wire.

No. WAGO connectors are clamps for splicing wire. EdgeConnect technology uses spring terminals within the wiring devices to terminate wires securely.

The internal spring grips the wire with constant force while screw terminal terminations may relax over time. Vibration that happens from normal wear and tear causes EdgeConnect spring terminals to tighten even further. As strands relax, the grip gets tighter, which doesn’t occur with traditional screw terminals.

Yes! They accept 14, 12, and 10 AWG solid or stranded wire. The product line offers a full range from 15A to 30A up to 480 Volts.

Yes, you can still split the circuit tab/break-off tab with pliers to control each receptacle separately.

There is a gauge on the back of the device showing the optimal strip length (approximately ½").

Yes, the added depth from the plungers is less than a quarter of an inch.

Yes, they use the same size wall plates and face coverings as traditional wiring devices.

The plungers are colour coded for easy installation and follow the traditional NEC labeling standard:

• Green – Ground wire
• White – Neutral wire
• Black and/or Red – Hot wires

No. Unlike traditional screw terminals, EdgeConnect devices have no exposed conductive material. It keeps you safe and eliminates the need for using electrical tape around the device.

Not yet. Please subscribe to stay in the know as we expand the product line.

Yes. If you need to perform a change-out or adjust your termination, simply use a 3/16” (or smaller) screwdriver and insert it into the top of the plunger. Use the molded fulcrum point as a lever and lift the plunger completely up to remove the wire.
